Motorola solutions MXM600 - Receiver Tests; Transmitter Tests; Call Processing Tests; Duplex Test

No. Test Name Test Setup Terminal Set-
up
Test Condi-
tions
Limits
Vector Error Max 10%
RMS,
Max 30%
Peak,
Max 5% Re-
sidual
7. Digital Duplex
Test (Tx)
RF Gen Level Private Mode -50 dBm
Burst Power 10–22 dBm
Timing Error <= 0.25 Sym-
bols
Frequency
Error
-/+ 100 Hz
Vector Error Max 10%
RMS,
Max 30%
Peak,
Max 5% Re-
sidual
4.3.1
Receiver Tests
● Simulate Base Station (Registration)
● RSSI Test
4.3.2
Transmitter Tests
● Power Profile
● Power Burst (Control Range)
● Tx Burst Timing Error
● Tx Frequency Error
● Vector Error RMS, Peak, and Residual
4.3.3
Call Processing Tests
● Talk Back
● Call to Mobile
4.3.4
Duplex Test
Digital Duplex Test (Tx)
MN009999A01-AA
Chapter 4: Test Setup and Testing
47
