Configuring the Control Channel number
2. Perform one of the following actions:
● For 350–390 MHz, enter 2400.
● For 380–430 MHz, enter 3700.
● For 410–470 MHz, enter 2509.
Configuring the Traffic Channel number
3. Perform one of the following actions:
● For 350–390 MHz, enter 2400.
● For 380–430 MHz, enter 3700.
● For 410–470 MHz, enter 2509.
NOTE: After entering the Control Channel number, the Traffic Controller number changes
automatically.
4. Turn ON the modulation and the AGC on the IFR.
5. Enter 3 for Slot.
6. Enter -90 for RF Gen Level.
7. Perform one of the following actions:
● For Mobile Power-on MXM600 radio, select Expected → 40dBm/10W.
8. To select TX, press TAB.
9. Select NORMAL for Burst.
Result: The setup for test equipment configuration is completed.
NOTE: The System Setup Configuration Data is saved after the power is turned off, but the manual test
setup is not saved.
4.5
RF Tests
This section lists the applicable RF Tests and its procedures for the radio.
4.5.1
Receiver Tests
The following procedures are for Receiver Tests.
4.5.1.1
Simulating Base Station (Registration)
Perform the following procedures to simulate the base station.
Procedure:
1. Turn the terminal ON.
