AP-7131 Access Point Product Reference Guide
2-2
2.1 Precautions
Before installing an AP-7131 model access point verify the following:
• Do not install in wet or dusty areas without additional protection. Contact a Motorola
representative for more information.
• Verify the environment has a continuous temperature range between -20° C to 50° C.
2.2 Requirements
The minimum installation requirements for a single-cell, peer-to-peer network:
• An AP-7131 (either a dual or single radio model)
• 48 Volt Power Supply Part No. 50-14000-247R or Power Injector
(Part No. AP-PSBIAS-1P3-AFR))
• A power outlet
• Dual-band antennae or an antenna specifically supporting the AP’s 2.4 or 5.2 GHz band
2.3 Package Contents
Check package contents for the correct model AP-7131 and applicable AP-7131 accessories. Each
available configuration (at a minimum), contains:
• AP-7131 model access point (accessories dependent on SKU ordered)
• AP-7131 Install Guide
• Accessories Bag (4 rubber feet and a LED light pipe and badge with label for above the
ceiling installations)
Contact the Motorola Support Center to report missing or improperly functioning items.
CAUTION Motorola recommends conducting a radio site survey prior to
installing an access point. A site survey is an excellent method of
documenting areas of radio interference and providing a tool for
device placement.
!
