Motorola AP-7131 - Above the Ceiling (Plenum) Installations

AP-7131 Access Point Product Reference Guide
2-16
11. The AP-7131 is ready to configure. For information on an AP-7131 default configuration, see
Getting Started on page 3-1. For specific details on AP-7131 system configurations, see
System Configuration on page 4-1.
2.7.3 Above the Ceiling (Plenum) Installations
An AP-7131 above the ceiling installation requires placing the AP-7131 above a suspended ceiling
and installing the provided light pipe under the ceiling tile for viewing the rear panel status LEDs of
the unit. An above the ceiling AP-7131 installation enables installations compliant with drop ceilings,
suspended ceilings and industry standard tiles from .625 to .75 inches thick.
The mounting hardware required to install the AP-7131 above a ceiling consists of:
• Light pipe
• Badge for light pipe
• Decal for badge
• Safety wire (strongly recommended)
• Security cable (optional)
To install the AP-7131 above a ceiling:
1. If possible, remove the adjacent ceiling tile from its frame and place it aside.
2. Install a safety wire, between 1.5mm (.06in.) and 2.5mm (.10in.) in diameter, in the ceiling
space.
3. If required, install and attach a security cable to the AP-7131’s lock port.
NOTE The AP-7131 is Plenum rated to UL2043 and NEC1999 to support above
the ceiling installations.
CAUTION Motorola does not recommend mounting the AP-7131 directly to any
suspended ceiling tile with a thickness less than 12.7mm (0.5in.) or a
suspended ceiling tile with an unsupported span greater than 660mm
(26in.). Motorola strongly recommends fitting the AP-7131 with a
safety wire suitable for supporting the weight of the device. The
safety wire should be a standard ceiling suspension cable or
equivalent steel wire between 1.59mm (.062in.) and 2.5mm (.10in.) in
diameter.
!
