AP-7131 Access Point Product Reference Guide
2-20
2.8.1 Dual Radio (2.4/5.2 Ghz) AP-7131 With Sensor Slot LEDs
A dual radio (2.4/5.2 Ghz) model AP-7131 has the following unique LED behavior:
2.8.2 Single Radio 2.4 Ghz AP-7131 LEDs
The single 2.4 Ghz radio model AP-7131 has the following unique LED behavior:
LED 1 LED 2 LED 3 LED 4 LED 5 LED 6
Blinking Red
indicates
booting. Solid
Red defines a
failure
condition.
White
defines
normal
operation
Green
defines
normal GE1
operation.
Yellow
defines a
collision
Green
defines
normal GE2
operation.
Yellow
defines a
collision
Amber
defines 5.2
Ghz radio as
configured
Emerald
defines 2.4
Ghz radio as
configured
Amber
5.2 Ghz radio
as present
and scanning.
Emerald
2.4 Ghz radio
as present
and scanning
LED 1 LED 2 LED 3 LED 4 LED 5
Blinking Red
indicates booting.
Solid Red defines
a failure
condition. White
defines normal
operation
Green defines
normal GE1
operation.
Yellow defines a
collision
Green defines
normal GE2
operation.
Yellow defines a
collision
Amber defines
5.2 Ghz radio as
present
Emerald defines
2.4 Ghz radio as
present
