AP-7131 Access Point Product Reference Guide
2-6
The AP-7131 5.2 GHz antenna suite includes the following models:
For detailed specifications on the 2.4 GHz and 5.2 GHz antennae mentioned in this section, see
section 2.4 GHz Antenna Matrix on page A-4 and section 5.2 GHz Antenna Matrix on page A-4. For a
more exhaustive overview of the antennas and associated components supported by the Motorola
access point family, refer to the Enterprise Wireless LAN Antenna Specification Guide available at
http://support.symbol.com/support/product/manuals.do.
2.5 AP-7131 Power Options
The power options for the AP-7131 include:
• AP-7131 48-Volt Power Supply (Part No. 50-14000-247R)
• AP-7131 Power Injector (Part No. AP-PSBIAS-1P3-AFR)
Part No. Antenna Type Nominal Net Gain (dBi)
ML-5299-WPNA1-01R Panel Antenna 13.0
ML-5299-HPA1-01R Wide-Band Omni-Directional
Antenna
5.0
ML-2452-APA2-0 Dual-Band 4.0
ML-2452-PTA2M3X3-1 Facade with 6 Element Antenna
Module
2.0
ML-2452-PTA3M3-036 3 Port MIMO Antenna 3.0
CAUTION An AP-7131 model access point cannot use the AP-5131
recommended 48-Volt Power Supply (Part No. 50-14000-243R), and
must use the 48-Volt Power Supply designed specifically for use with
an AP-7131 model access point (Part No. 50-14000-247R).
Additionally, a new single-port Power of Ethernet Power Injector is
available for use with the AP-7131 (Part No. AP-PSBIAS-1P3-AFR).
!
