Hardware Installation
2-21
2.8.3 Single Radio 5.2 Ghz AP-7131 LEDs
The single 5.2 Ghz radio model AP-7131 has the following unique LED behavior:
2.8.4 Rear AP-7131 LED
The LED on the rear (bottom) of the AP-7131 is viewed using a single (customer installed) extended
light pipe, adjusted as required to suit above the ceiling installations. The LED displayed using the
light pipe has the following color display and functionality:
LED 1 LED 2 LED 3 LED 4 LED 5
Blinking Red
indicates booting.
Solid Red defines
a failure
condition. White
defines normal
operation
Green defines
normal GE1
operation.
Yellow defines a
collision
Green defines
normal GE2
operation.
Yellow defines a
collision
Amber defines
5.2 Ghz radio as
present
Emerald defines
2.4 Ghz radio as
present
LED 1
White/Red defining power and boot
status
