Identifying Status Indicators
English
19
LED Indicators in Dark Mode†
For covert operation, the LED can be preprogrammed to turn off
at specific zone channels. During operation in these zone
channels you do not see the LED blinking, instead you can use
Voice Announcement to hear and confirm the operation status.
Hence, It is recommended to duplicate the channel
programming into separate zone and have associated Voice
Announcement tied to zone to help indicate the LED on/off
state, for example Light Off Zone 1. Using zone control in this
case eases going into and out of the zone channel
preprogrammed with the LED on/off setting.
Solid green
Short blinking blue
with long interval
Radio is reading or upgrading by CPS.
–
Blinking blue three
times
Bluetooth is powering on or off.
– Rapid Blinking blue Radio is waiting to be paired when no device is connected with radio in Bluetooth.
–
Blinking blue at
heartbeat pace
Radio is connected with at least a device in Bluetooth link.
–
Solid blue for two
seconds
Bluetooth device is connected or disconnected successfully.
– Blinking blue Radio is clearing Bluetooth pairing information.
–
Rapid blinking blue
for two seconds
Radio fails to connect or disconnect from a device.
– Solid blue Radio is powering up with Option Board error.
Note: No LED indication occurs when your radio receives a clear (non-secured) transmission in trunking Mode.
Transmit/Receive LED Bluetooth LED Status
