Motorola ASTRO APX 6000XE Series User Manual

Advanced Features
English
150
Accessing the Radio Information
This feature displays the following information of your radio:
Note: Press
H at any time to return to the Home screen.
Procedure:
Press the preprogrammed Info button and proceed to Step 3.
OR
Follow the procedure below.
1 < or > to Info.
2 Press the Menu Select button directly below Info.
3 U or D to Radio Info and press the Menu Select button
directly below Sel.
4 The display shows the Information screen.
5 U or D to scroll through the various information.
OR
Press the Menu Select button directly below Back to return
to the previous screen.
OR
Press H to return to the Home screen.
• Host Version • DSP Version
• Secure Version • KG (Secure Algorithm)
• Model Number • Serial Number
• ESN • Flash Size & Type
• Flash Code • RF Band
• Tuning Version • Processor Version
• Option Board Type
(optional)
• Option Board Serial Number
(optional)
• Option Board Bluetooth
Address (optional)
• Option Board Software Version
(optional)
• Expansion Board Type
(optional)
• Language Pack ID and Version
(only when the language of the
display is set to non-English)


Motorola ASTRO APX 6000XE Series Specifications

General

Frequency Range	700/800 MHz, VHF, UHF Range 1, UHF Range 2
Operating Temperature	-30°C to +60°C
P25 Phase 1 & 2	Yes
Bluetooth	Yes
GPS	Yes
Weight	381 g (with standard battery)
Encryption	AES, DES-OFB
Intrinsically Safe	Yes
