Identifying Radio Controls

English

Radio Parts and Controls

Antenna

LED

Accessory

Connector

On/Off/Volume

Control Knob

Keypad

Home Button

4-Way

Navigation

Button

Battery Latch

Menu Select

Buttons

2-Position Concentric

Switch*

3-Position A/B/C

Switch*

Battery

16-Position

Select Knob*

Top

Display

Main

Speaker

Side Button 2*

Side Button 1*

Push-to-Talk

(PTT) Button

Microphone

* These radio controls/buttons are programmable.

Top Side (Select)

Button*

Microphone

Main Display

Data Feature

Button

Top (Orange)

Button*

Bluetooth

Pairing

Indicator
