Identifying Radio Controls

English

Keypad Characters – Lowercase Mode

Number of Times Key is Pressed

Key123456789101112131415161718192021

1. ,?!;@_-*#&$/+=\“ ‘ ()

abc

de f

gh i

jkl

mn o

pqr s

tuv

wxyz

Toggle between mixed case mode, uppercase mode, and lowercase mode.

Space

Toggle between numeric and letter mode.


