Advanced Features
English
45
The Volume knob, DIM button, Front/Rear (F/R) softkey and
Emergency button remain active on the inactive control head,
while all other controls are disabled. Emergency footswitch and
VIP inputs remain active on the inactive control head. The VIP
input control head is configurable in the CPS and VIP should be
attached to the control head selected in the CPS.
Note: Only two (2) control heads are supported in the one
active mode.
Follow the procedure below to change the command between
the two control heads.
Procedure:
Press the Menu Select button directly below F/R.
OR
Press the Menu Select button preprogrammed user button on
the keypad microphone.
Transceiver
Z1
ZONE
CHAN
PWR
SQL
REMOTE
F/R
Active Radio
Non-Active Radio
O5Head_6875947m01.book Page 45 Tuesday, November 1, 2011 12:06 PM
