8
Introduction
Belt-Clip Installation and Removal
The battery must be removed from the radio before the belt clip
can be installed or removed.
Installing the Belt Clip
1. Hold the battery in one hand so that the top
of the battery faces upward, and the back of
the battery faces you.
2. Holding the belt clip in the other hand with
its top facing upward, align the slide
assembly on the front of the belt clip with
the slots on the back of the battery.
3. Slide the belt clip downward toward the
bottom of the battery until the belt clip
“clicks” in place.
Removing the Belt Clip
1. Hold the battery (with belt clip installed) in
one hand so that the top of the battery faces
upward, and the front (radio side) of the
battery faces you.
2. At the top of the battery, press down on the
belt clip’s metal tab and slide the belt clip
upward until it disengages from the battery.
3. Continue to slide the belt clip upward until it
is free from the battery.
Note
Slide
Assembly
Slots
Belt Clip
Battery
