November 16, 2006 6881094C31-E

7-8 Troubleshooting Tables: List of Board and IC Signals

G3 ADDRESS 13 No

G4 ADDRESS 14 No

F3 ADDRESS 15 No

F4 ADDRESS 16 No

E4 ADDRESS 17 No

D3 ADDRESS 18 No

H1 ADDRESS 19 No

D1 GROUND No

E6 GROUND No

E3 GROUND No

H6 NOT USED No

G2 NOT USED No

G1 DATA 15 No

F1 DATA 14 No

F2 DATA 13 No

E2 DATA 12 No

D2 DATA 11 No

C2 DATA 10 No

C1 DATA 9 No

B1 DATA 8 No

G6 DATA 7 R435** No

F6 DATA 6 R434** No

F5 DATA 5 R433** No

E5 DATA 4 R432** No

D5 DATA 3 R431** No

C6 DATA 2 R430** No

C5 DATA 1 R429** No

B6 DATA 0 R428** No

D6 VSW2 C411* 1.875 V Yes

E1 VSW2 C411* 1.875 V Yes

Table 7-6. U403 SRAM Pinouts (Continued)

U403

Pin No.

Description To/From Comment

Accessible

on Vocon?

Motorola ASTRO XTS 5000 Detailed Service Manual
