Motorola ASTRO XTS 5000 Detailed Service Manual

November 16, 2006 6881094C31-E
xxiv Portable Radio Model Numbering System
ASTRO XTS 5000 700–800 MHz Model Chart
MODEL NUMBER DESCRIPTION
H18UCC9PW5AN 700/800 MHz 1-3 Watts ASTRO XTS 5000 Model I
H18UCF9PW6AN 700/800 MHz 1-3 Watts ASTRO XTS 5000 Model II
H18UCH9PW7AN 700/800 MHz 1-3 Watts ASTRO XTS 5000 Model III
ITEM NUMBER DESCRIPTION
XXX NUF3577_ Board, Transceiver (700/800 MHz)
XXX NTN9564_ or,
NNTN4717_ or,
NNTN5567_
Board, VOCON*
Board, VOCON*
Board, Mako VOCON*
XXX — Belt Clip Kit (Refer to the Basic Service Manual accessories appendix)
XXX — Battery (Refer to Table 2-1 and Table 2-2 on page 2-1)
X NTN9682_ Kit, Front Cover, Model I
X NTN9681_ Kit, Front Cover, Model II
X NTN9680_ Kit, Front Cover, Model III
XXX — Antenna, 700/800 MHz (Refer to the Basic Service Manual accessories appendix)
XXX 0985973B02 Assembly, B+ Connector
XXX 1505579Z01 Cover, Accessory Connector
X 2685567D01 Assembly, VOCON Shield, Model I
X 2685567D02 Assembly, VOCON Shield-Keypad, Model II
X 2685567D03 Assembly, VOCON Shield-Keypad, Model III
XXX 2685220D08 Shield, RF (Transceiver) Board
XXX 2785219D01 Assembly, Casting
XXX 2885866A01 Connector, Compression, 26-Pin
XXX 3285900E01 Gasket, Antenna O-Ring
XXX 3205349Z03 Seal, Main
XXX 3205351Z02 Seal, B+
XXX 3285877B02 Seal, Port
XXX 3385873B01 Label, Port
XX 7285726C01 or,
7285726C02
Module, LCD Display (for use only with the NTN9564_VOCON board)
Module, LCD Display (for use only with the NNTN4717_VOCON board)
XX 7585189D01 Pad, Display Locator
XXX 7585936D04 Pad, RF
XXX 7585139E01 Pad, Battery holder
X 7585104D02 Keypad, Model II
X 7585104D01 Keypad, Model III
Notes:
X =Item Included
* =The radio’s model number, FLASHcode, Host code, and DSP code are required when placing an order for the VOCON Board.
• The model number and (sometimes) the FLASHcode can be found on the FCC label on the back of the radio.
• The model number, Host code, DSP code, and (sometimes) the FLASHcode can be found by putting a Model II or III
radio into the Test Mode.
• The model number, Host code, DSP code, and FLASHcode can be found by using the Programming Cable (RKN4105_ or
RKN4106_) and the CPS to read a Model I, II, or III radio.
