Motorola ASTRO XTS 5000 Detailed Service Manual

6881094C31-E November 16, 2006
Portable Radio Model Numbering System xxiii
ASTRO XTS 5000 R (Ruggedized) UHF Range 2 Model Chart
MODEL NUMBER DESCRIPTION
H18SDC9PW5AN w/Q155FL Opt Ruggedized UHF Range 2, 1-5 Watts ASTRO XTS 5000 Model I
H18SDF9PW6AN w/Q155FM Opt Ruggedized UHF Range 2, 1-5 Watts ASTRO XTS 5000 Model II
H18SDH9PW7AN w/Q155FN Opt Ruggedized UHF Range 2, 1-5 Watts ASTRO XTS 5000 Model III
H18SDF9PW5AN w/Q155FZ Opt Ruggedized Yellow UHF Range 2, 1-5 Watts ASTRO XTS 5000 Model I
H18SDF9PW6AN w/Q155FZ Opt Ruggedized Yellow UHF Range 2, 1-5 Watts ASTRO XTS 5000 Model II
H18SDH9PW7AN w/Q155GA Opt Ruggedized Yellow UHF Range 2, 1-5 Watts ASTRO XTS 5000 Model III
ITEM NUMBER DESCRIPTION
XXXXXX NLE4273_ Board, Transceiver (UHF R2)
XXXXXX NNTN4717_ or,
NNTN5567_
Board, VOCON*
Board, Mako VOCON*
XXXXXX — Belt Clip Kit (Refer to the Basic Service Manual accessories appendix)
XXXXXX — Battery (Refer to Table 2-1 and Table 2-2 on page 2-1)
X NNTN4059_ Kit, Front Cover, Model I, Ruggedized
X NNTN4060_ Kit, Front Cover, Model II, Ruggedized
X NNTN4061_ Kit, Front Cover, Model III, Ruggedized
X NTN9685_ Kit, Yellow Front Cover, Model I, Ruggedized
X NTN9684_ Kit, Yellow Front Cover, Model II, Ruggedized
X NTN9683_ Kit, Yellow Front Cover, Model III, Ruggedized
XXXXXX — Antenna, UHF (Refer to the Basic Service Manual accessories appendix)
XXXXXX 0985973B02 Assembly, B+ Connector
XXXXXX 1505579Z01 Cover, Accessory Connector
X X 2685567D01 Assembly, VOCON Shield, Model I
X X 2685567D02 Assembly, VOCON Shield-Keypad, Model II
X X 2685567D03 Assembly, VOCON Shield-Keypad, Model III
XXXXXX 2685220D02 Shield, RF (Transceiver) Board
XXXXXX 2785219D04 Assembly, Ruggedized Casting
XXXXXX 2885866A01 Connector, Compression, 26-Pin
XXXXXX 3205082E96 Gasket, Antenna O-Ring
XXXXXX 3205349Z03 Seal, Main
XXXXXX 3205351Z02 Seal, B+ Ruggedized
XXXXXX 3285877B02 Seal, Port
XXXXXX 3385873B01 Label, Port
XX XX 7285726C03 Module, LCD Display
XX XX 7585189D01 Pad, Display Locator
X X 7585104D02 Keypad, Model II
X X 7585104D01 Keypad, Model III
Notes:
X =Item Included
* =The radio’s model number, FLASHcode, Host code, and DSP code are required when placing an order for the VOCON Board.
• The model number and (sometimes) the FLASHcode can be found on the FCC label on the back of the radio.
• The model number, Host code, DSP code, and (sometimes) the FLASHcode can be found by putting a Model II or III
radio into the Test Mode.
• The model number, Host code, DSP code, and FLASHcode can be found by using the Programming Cable (RKN4105_ or
RKN4106_) and the CPS to read a Model I, II, or III radio.
