6881094C31-E November 16, 2006
Troubleshooting Procedures: Power-Up Self-Check Errors 4-5
4.5 Power-Up Self-Check Errors
Each time the radio is turned on, the MCU and DSP perform a series of internal diagnostics. These
diagnostics consist of checking such programmable devices as the FLASH ROMs, the EEPROM,
and SRAM devices.
Problems detected during the power-up self-check routines are presented as error codes on the
radio’s display. For non-display radios, the problem is presented at power up by a single, low-
frequency tone. Table 4-4 lists possible error codes, a description of each error code, and a
recommended corrective action.
Table 4-3. Standard Operating Bias (only for kit NNTN5567_)
Signal Name
Nominal
Value
Tolerance VOCON Board Source
Gated_32_CLK 32.768KHz ± 400ppm R543
CKIH 16.8MHz R457
16.8_MHz 16.8MHz C450
POR 2.9Vdc ±5% R725
MAKO_RESET 2.9Vdc ±5% TP_MAKO_RESET
VSW1 3.6Vdc ±5% R511
VSW2 2.3Vdc ±5% C515
V_2.9 2.9Vdc ±5% C523
UNSW_B+ 7.5Vdc 6.0-9.0Vdc R525
SW_B+ 7.5Vdc 6.0-9.0Vdc R517
VCC5 5.0Vdc ±5% L505
VSAVE 2.5Vdc ±5% C504
RF_SW_B+ 7.5Vdc 6.0-9.0Vdc C530
Table 4-4. Power-Up Self-Check Error Codes
Error
Code
Description Corrective Action
01/02 FLASH ROM codeplug Checksum Non-Fatal Error Reprogram the codeplug
01/12 Security Partition Checksum Non-Fatal Error Send radio to depot
01/20 ABACUS Tune Failure Non-Fatal Error Turn radio off, then on
01/22 Tuning Codeplug Checksum Non-Fatal Error Send radio to depot
01/81 Host ROM Checksum Fatal Error Send radio to depot
01/82 FLASH ROM Codeplug Checksum Fatal Error Reprogram the codeplug
