xxii Portable Radio Model Numbering System
ASTRO XTS 5000 UHF Range 2 Model Chart
MODEL NUMBER DESCRIPTION
H18SDC9PW5AN UHF Range 2, 1-5 Watts ASTRO XTS 5000 Model I
H18SDF9PW6AN UHF Range 2, 1-5 Watts ASTRO XTS 5000 Model II
H18SDH9PW7AN UHF Range 2, 1-5 Watts ASTRO XTS 5000 Model III
ITEM NUMBER DESCRIPTION
XXX NLE4273_ Board, Transceiver (UHF R2)
XXX NNTN4717_ or,
NNTN5567_
Board, VOCON*
Board, Mako VOCON*
XXX — Belt Clip Kit (Refer to the Basic Service Manual accessories appendix)
XXX — Battery (Refer to Table 2-1 and Table 2-2 on page 2-1)
X NTN9682_ Kit, Front Cover, Model I
X NTN9681_ Kit, Front Cover, Model II
X NTN9680_ Kit, Front Cover, Model III
XXX — Antenna, UHF (Refer to the Basic Service Manual accessories appendix)
XXX 0985973B01 Assembly, B+ Connector
XXX 1505579Z01 Cover, Accessory Connector
X 2685567D01 Assembly, VOCON Shield, Model I
X 2685567D02 Assembly, VOCON Shield-Keypad, Model II
X 2685567D03 Assembly, VOCON Shield-Keypad, Model III
XXX 2685220D02 Shield, RF (Transceiver) Board
XXX 2785219D01 Assembly, Casting
XXX 2885866A01 Connector, Compression, 26-Pin
XXX 3205082E96 Gasket, Antenna O-Ring
XXX 3205349Z03 Seal, Main
XXX 3205351Z02 Seal, B+
XXX 3285877B02 Seal, Port
XXX 3385873B01 Label, Port
XX 7285726C03 Module, LCD Display
XX 7585189D01 Pad, Display Locator
X 7585104D02 Keypad, Model II
X 7585104D01 Keypad, Model III
Notes:
X =Item Included
* =The radio’s model number, FLASHcode, Host code, and DSP code are required when placing an order for the VOCON
Board.
• The model number and (sometimes) the FLASHcode can be found on the FCC label on the back of the radio.
• The model number, Host code, DSP code, and (sometimes) the FLASHcode can be found by putting a Model II or III
radio into the Test Mode.
• The model number, Host code, DSP code, and FLASHcode can be found by using the Programming Cable
(RKN4105_ or RKN4106_) and the CPS to read a Model I, II, or III radio.
