November 16, 2006 6881094C31-E

7-10 Troubleshooting Tables: List of Board and IC Signals

E1 WAKEUP J701, pin 26 Yes

H6 SPARE2_ENC J701, pin 34 Yes

G3 NOT USED No

E7 NOT USED No

A8 NOT USED No

F8 MISOA_SEL U406, pin 2 Yes

E8 NOT USED No

G8 NOT USED No

C3 NOT USED No

D4 LOCK_DET C123 Active Low Yes

A2 TG2 R234 Yes

B2 RTA3 R241 Yes

A3 RTA2 R239 Yes

B3 RTA1 R236 Yes

B4 RTA0 R235 Yes

A7 VSW2 E401* 1.875 V Yes

P3 VSW2 E401* 1.875 V Yes

P6 VSW2 E401* 1.875 V Yes

T9 VSW2 E401* 1.875 V Yes

N10 VSW2 E401* 1.875 V Yes

R16 VSW2 E401* 1.875 V Yes

H9 V2 E402* 3.0 V Yes

G9 V2 E402* 3.0 V Yes

E15 V2 E402* 3.0 V Yes

A16 V2 E402* 3.0 V Yes

K10 V2 E402* 3.0 V Yes

C12 V2 E402* 3.0 V Yes

D8 V2 E402* 3.0 V Yes

B7 V2 E402* 3.0 V Yes

A4 V2 E402* 3.0 V Yes

A16 V2 E402* 3.0 V Yes

Table 7-7. U401 Patriot MCU/DSP IC Pinouts (Continued)

U401

Pin No.

Description To/From Comment

Accessible

on Vocon?
