Schematics, Board Overlays, and Parts Lists: VOCON Boards 8-147
6881094C31-E November 16, 2006
NNTN4819A VOCON Board Parts List
Ref. Des. Part Number Description
B101 2480574F01 IND FERRITE CHIP 600
OHM 0603
B104 2462586G33 INDUCTOR CHIP FERRITE
BEADS
B201 2480574F01 IND FERRITE CHIP 600
OHM 0603
B502 2480574F01 IND FERRITE CHIP 600
OHM 0603
B503 2480574F01 IND FERRITE CHIP 600
OHM 0603
BATT 6003710K08 BATT COIN 3.3V LIION
C101 2113743L09 CAP CHIP 470 PF 10% X7R
C102 2113743L09 CAP CHIP 470 PF 10% X7R
C103 2113743L09 CAP CHIP 470 PF 10% X7R
C104 2113743L09 CAP CHIP 470 PF 10% X7R
C106 2113743L09 CAP CHIP 470 PF 10% X7R
C107 2113743L09 CAP CHIP 470 PF 10% X7R
C108 2113743L09 CAP CHIP 470 PF 10% X7R
C109 2113743N38 CAP CHIP 33.0 PF 5% COG
C110 2113743N38 CAP CHIP 33.0 PF 5% COG
C111 2113743N38 CAP CHIP 33.0 PF 5% COG
C112 2113743N50 CAP CHIP 100 PF 5% COG
C113 2113743L09 CAP CHIP 470 PF 10% X7R
C114 2113743L09 CAP CHIP 470 PF 10% X7R
C115 2113743L09 CAP CHIP 470 PF 10% X7R
C116 2113743N38 CAP CHIP 33.0 PF 5% COG
C117 2113743L09 CAP CHIP 470 PF 10% X7R
C118 2113743N38 CAP CHIP 33.0 PF 5% COG
C119 2113743N38 CAP CHIP 33.0 PF 5% COG
C120 2113743N38 CAP CHIP 33.0 PF 5% COG
C121 2113743N38 CAP CHIP 33.0 PF 5% COG
C122 2113743N38 CAP CHIP 33.0 PF 5% COG
C123 2113743L09 CAP CHIP 470 PF 10% X7R
C124 2113743L09 CAP CHIP 470 PF 10% X7R
C125 2113743L09 CAP CHIP 470 PF 10% X7R
C126 2113743L09 CAP CHIP 470 PF 10% X7R
C127 2113743L09 CAP CHIP 470 PF 10% X7R
C128 2113743L09 CAP CHIP 470 PF 10% X7R
C129 2113743L09 CAP CHIP 470 PF 10% X7R
C130 2113743L09 CAP CHIP 470 PF 10% X7R
C131 2113743L09 CAP CHIP 470 PF 10% X7R
C132 2113743L09 CAP CHIP 470 PF 10% X7R
C133 2113743L09 CAP CHIP 470 PF 10% X7R
C134 2113743L09 CAP CHIP 470 PF 10% X7R
C135 2113743L41 CAP CHIP 10000 PF 10%
X7R
C136 2113743L09 CAP CHIP 470 PF 10% X7R
C137 2113743A31 CAP CHIP 1.0UF 10% X7R
C138 2113743L09 CAP CHIP 470 PF 10% X7R
C170 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C171 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C172 NOTPLACED NOTPLACED
C201 2113743L09 CAP CHIP 470 PF 10% X7R
C202 2113743L09 CAP CHIP 470 PF 10% X7R
C203 2113743L09 CAP CHIP 470 PF 10% X7R
C204 2113743L09 CAP CHIP 470 PF 10% X7R
C205 2113743L41 CAP CHIP 10000 PF 10%
X7R
C206 2113743L41 CAP CHIP 10000 PF 10%
X7R
C207 2113743L09 CAP CHIP 470 PF 10% X7R
C208 2113743L09 CAP CHIP 470 PF 10% X7R
C209 2113743L17 CAP CHIP 1000 PF 10%
X7R
C210 2113743L09 CAP CHIP 470 PF 10% X7R
C211 2113743L09 CAP CHIP 470 PF 10% X7R
C212 2113743L09 CAP CHIP 470 PF 10% X7R
C213 2113743L09 CAP CHIP 470 PF 10% X7R
C214 2113743L09 CAP CHIP 470 PF 10% X7R
C215 2113743L09 CAP CHIP 470 PF 10% X7R
C216 2113743L09 CAP CHIP 470 PF 10% X7R
C217 2113743L09 CAP CHIP 470 PF 10% X7R
C218 2113743L09 CAP CHIP 470 PF 10% X7R
C219 2113743L09 CAP CHIP 470 PF 10% X7R
C220 2113743L09 CAP CHIP 470 PF 10% X7R
C221 2113743L09 CAP CHIP 470 PF 10% X7R
C223 2113743L09 CAP CHIP 470 PF 10% X7R
C224 2113743N38 CAP CHIP 33.0 PF 5% COG
Ref. Des. Part Number Description
C225 2113743L09 CAP CHIP 470 PF 10% X7R
C226 2113743N38 CAP CHIP 33.0 PF 5% COG
C227 2113743L09 CAP CHIP 470 PF 10% X7R
C230 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C231 2113743L09 CAP CHIP 470 PF 10% X7R
C232 2113743L09 CAP CHIP 470 PF 10% X7R
C233 2113743N50 CAP CHIP 100 PF 5% COG
C234 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C250 NOTPLACED NOTPLACED
C251 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C252 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C253 2113743A19 CAP CHIP .100 UF 10%
X7R
C254 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C256 NOTPLACED NOTPLACED
C270 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C301 2113743E20 CAP CHIP .10 UF 10%
C302 2113743L41 CAP CHIP 10000 PF 10%
X7R
C303 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C304 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C305 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C306 2113743N50 CAP CHIP 100 PF 5% COG
C308 2113743N20 CAP CHIP 5.6PF +-.5PF
COG
C309 2113743N20 CAP CHIP 5.6PF +-.5PF
COG
C310 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C311 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C312 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C313 2113743N28 CAP CHIP 12.0 PF 5% COG
Ref. Des. Part Number Description
C314 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C315 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C316 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C317 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C318 NOTPLACED NOTPLACED
C320 2113743L09 CAP CHIP 470 PF 10% X7R
C321 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C322 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C323 NOTPLACED NOTPLACED
C324 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C325 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C326 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C327 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C328 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C329 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C330 2113743N50 CAP CHIP 100 PF 5% COG
C331 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C332 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C333 2113743N44 CAP CHIP 56.0 PF 5% COG
C401 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C404 NOTPLACED NOTPLACED
C409 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C411 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C413 2113743E04 CAP CER CHIP .016UF
C414 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C415 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
Ref. Des. Part Number Description
