RS-232 Interface 6 - 3
RS-232 Parameter Defaults
Table 6-1 lists the defaults for RS-232 host parameters. To change any option, scan the appropriate bar
code(s) provided in the RS-232 Host Parameters section beginning on page 6-4.
NOTE See Appendix A, Standard Default Parameters for all user preferences, hosts, symbologies, and
miscellaneous default parameters.
Table 6-1
RS-232 Host Default Table
Parameter Default
Page
Number
RS-232 Host Parameters
RS-232 Host Types Standard
6-6
Baud Rate 9600
6-8
Parity Type None
6-9
Stop Bits 1
6-10
Data Bits 8-bit
6-10
Check Receive Errors Enable
6-11
Hardware Handshaking None
6-11
Software Handshaking None
6-13
Host Serial Response Timeout 2 Sec
6-15
RTS Line State Low RTS
6-16
Beep on <BEL> Disable
6-16
Intercharacter Delay 0 msec
6-17
Nixdorf Beep/LED Options Normal Operation
6-18
Ignore Unknown Characters Send Bar Code
6-18
Note: The DS9208 supports one stop bit only.
