Motorola DS9208-1D User Manual

Data Capture 2 - 5
Scanning
The DS9208 has an integrated, adjustable stand to easily accommodate both presentation and triggered
scanning.
Presentation Mode Scanning
For standard operation, the digital scanner is in presentation mode and automatically decodes bar codes that
are presented in its field of view.
Figure 2-2 Scanning in Presentation Mode, Hands-Free
Red Out of rule memory. Erase some existing rules, then try to save rule again.
Entry error, wrong bar code scanned, or criteria/action list is too long for a rule.
Re-enter criterion or action.
Firmware update
Red, alternating between
solid and fast blinking
Firmware download is completing. Wait for this indicator to complete before using
the scanner. This indicator is followed by a low/medium/high power up beep.
Table 2-2 Standard LED Definitions
LED Indication
