Motorola DS9208-1D - Mounting Templates

1 - 8 DS9208-1D Product Reference Guide
Mounting Templates
Use the following templates to facilitate the proper placement of brackets and screws.
Figure 1-8 Wall Mount Bracket Template
Figure 1-9 Locking Mount Bracket Template
40 mm
54 mm
49 mm
