8- 10 MC68000 8-/16-/32-MICROPROCESSORS UISER'S MANUAL MOTOROLA
Table 8-12. Miscellaneous Instruction Execution Times
Instruction Size Register Memory
ANDI to CCR Byte 20(3/0) —
ANDI to SR Word 20(3/0) —
CHK (No Trap) — 10(1/0)+ —
EORI to CCR Byte 20(3/0) —
EORI to SR Word 20(3/0) —
ORI to CCR Byte 20(3/0) —
ORI to SR Word 20(3/0) —
MOVE from SR — 6(1/0) 8(1/1)+
MOVE to CCR — 12(1/0) 12(1/0)+
MOVE to SR — 12(2/0) 12(2/0)+
EXG — 6(1/0) —
EXT Word 4(1/0) —
Long 4(1/0) —
LINK — 16(2/2) —
MOVE from USP — 4(1/0) —
MOVE to USP — 4(1/0) —
NOP — 4(1/0) —
RESET — 132(1/0) —
RTE — 20(5/0) —
RTR — 20(2/0) —
RTS — 16(4/0) —
STOP — 4(0/0) —
SWAP — 4(1/0) —
TRAPV — 4(1/0) —
UNLK — 12(3/0) —
+Add effective address calculation time.
Table 8-13. Move Peripheral Instruction Execution Times
Instruction Size Register → Memory Memory → Register
MOVEP Word 16(2/2) 16(4/0)
Long 24(2/4) 24(6/0)
8.12 EXCEPTION PROCESSING EXECUTION TIMES
Table 8-14 lists the timing data for exception processing. The numbers of clock periods
include the times for all stacking, the vector fetch, and the fetch of the first instruction of
