9.4 IMMEDIATE INSTRUCTION EXECUTION TIMES
The numbers of clock periods shown in Table 9-8 include the times to fetch immediate
operands, perform the operations, store the results, and read the next operation. The total
number of clock periods, the number of read cycles, and the number of write cycles are
shown in the previously described format. The number of clock periods, the number of
read cycles, and the number of write cycles, respectively, must be added to those of the
effective address calculation where indicated by a plus sign (+).
In Tables 9-8, the following notation applies:
# — Immediate operand
Dn — Data register operand
An — Address register operand
M — Memory operand
Table 9-8. Immediate Instruction Execution Times
Instruction Size op #, Dn op #, An op #, M
ADDI Byte, Word 8(2/0) —12(2/1)+
Long 14(3/0) —20(3/2)+
ADDQ Byte, Word 4(1/0) 4(1/0)* 8(1/2)+
Long 8(1/0) 8(1/1) 12(1/2)+
ANDI Byte, Word 8(2/0) —12(2/1)+
Long 14(3/0) —20(3/1)+
CMPI Byte, Word 8(2/0) —8(2/0)+
Long 12(3/0) —12(3/0)+
EORI Byte, Word 8(2/0) —12(2/1)+
Long 14(3/0) —20(3/2)+
MOVEQ Long 4(1/0) ——
ORI Byte, Word 8(2/0) —12(2/1)+
Long 14(3/0) —20(3/2)+
SUBI Byte, Word 8(2/0) —12(2/1)+
Long 14(3/0) —20(3/2)+
SUBQ Byte, Word 4(1/0) 4(1/0)* 8(1/1)+
Long 8(1/0) 8(1/0) 12(1/2)+
+Add effective address calculation time.
*Word only.
9.5 SINGLE OPERAND INSTRUCTION EXECUTION TIMES
Tables 9-9, 9-10, and 9-11 list the timing data for the single operand instructions. The total
number of clock periods, the number of read cycles, and the number of write cycles are
shown in the previously described format. The number of clock periods, the number of
read cycles, and the number of write cycles, respectively, must be added to those of the
effective address calculation where indicated by a plus sign (+).
