3.11 SIGNAL SUMMARY
Table 3-4 summarizes the signals discussed in the preceding paragraphs.
Table 3-4. Signal Summary
Hi-Z
Signal Name Mnemonic Input/Output Active State On
HALT
On Bus
Relinquish
Address Bus A0–A23 Output High Yes Yes
Data Bus D0–D15 Input/Output High Yes Yes
Address Strobe AS Output Low No Yes
Read/Write R/W Output Read-High
Write-Low
No Yes
Data Strobe DS Output Low No Yes
Upper and Lower Data Strobes UDS, LDS Output Low No Yes
Data Transfer Acknowledge DTACK Input Low No No
Bus Request BR Input Low No No
Bus Grant BG Output Low No No
Bus Grant Acknowledge BGACK Input Low No No
Interrupt Priority Level IPL 0, IPL 1,
IPL 2
Input Low No No
Bus Error BERR Input Low No No
Mode MODE Input High — —
Reset RESET Input/Output Low No* No*
Halt HALT Input/Output Low No* No*
Enable E Output High No No
Valid Memory Address VMA Output Low No Yes
Valid Peripheral Address VPA Input Low No No
Function Code Output FC0, FC1,
FC2
Output High No Yes
Clock CLK Input High No No
Power Input V
CC
Input — — —
Ground GND Input — — —
*Open drain.
