SECTION 11
ORDERING INFORMATION AND MECHANICAL DATA
This section provides pin assignments and package dimensions for the devices described
in this manual.
11.1 PIN ASSIGNMENTS
Package 68000 68008 68010 68HC000 68HC001 68EC000
64-Pin Dual-In-Line ✔✔✔
68-Terminal Pin Grid Array ✔✔✔✔
64-Lead Quad Pack ✔
68-Lead Quad Flat Pack ✔ ✔✔✔✔
52-Lead Quad ✔
48-Pin Dual-In-Line ✔
