MOTOROLA M68000 8-/16-/32-BIT MICROPROCESSORS USER'S MANUAL 11-11
64
32
1
A
B
F
G
D
C
N
K
M
L
J
P SUFFIX
754-01
NOTES:
1. DIMENSIONS A AND B ARE DATUMS.
3. POSITIONAL TOLERANCE FOR LEADS
(DIMENSION D):
4. DIMENSION B DOES NOT INCLUDEMOLD FLASH.
5. DIMENSION L IS TO CENTER OF LEADS WHEN FORMED
PARALLEL.
6. DIMENSIONING AND TOLERANCING PER ANSI Y14.5, 1982.
DIM
MILLIMETERS INCHES
MIN MAX MIN MAX
A
B
C
D
F
G
J
K
L
M
N
81.16 81.91 3.195 3.225
20.17 20.57 0.790 0.810
4.83 5.84 0.190 0.230
0.33 0.53 0.013 0.021
1.27 1.77 0.050 0.070
2.54 BSC 0.100 BSC
0.20
0.38 0.008 0.015
3.05
3.55 0.120 0.140
22.86 BSC 0.9 00 BSC
015015
0.51 1.02 0.020 0.040
33
T
2. -T- IS SEATING PLANE.
M
0.25 (0.010) T A
M
M
B
Figure 11-10. Case 754-01—R and P Suffix
