Accessories 6 - 9
Four Slot Battery Charger
This section describes how to use the Four Slot Battery Charger to charge up to four MC75 batteries.
MC75 Battery Shim Installation
Before charging a spare battery, snap the MC75 shim into the battery slot as shown in Figure 6-9.
Figure 6-9
MC75 Battery Shim Installation
Spare Battery Charging
1. Connect the charger to a power source.
2. Insert the spare battery into a spare battery charging well and gently press down on the battery to ensure
proper contact.
NOTE To purchase additional shims, contact your local account manager or Motorola, Inc. Part number:
KT-76490-01R.
