6 - 22 MAINTENANCE
Table 6-5 Transceiver Parts List
Item No. Description Part Number
1 Chassis (item 2 included) 2766532A01
2 Gasket, Enhanced Control Head 3202620Y01
3 Main PCB (items 4 – 7 included) refer to Appendix: Service Kits
4 BNC Antenna Connector 0986166B01
5 Power Connector 0986165B01
6 Accessory Connector 0986105B01
7 Flex to optional GPS 3066541B01
8 Connector Assembly 2886122B02
9 Connector Housing 16Pos. 1580922V01
10 Gasket Accessory Connector 3202606Y02
11 Gasket Cover 3286095B01
12 Cover (item 11 included) 1566511A02
13 Screw T20, 6x (M4) 0310911A30
14 Cover, Plastic 1586170B01
15 Silicon Pressurepad for UHF only 7566500A01
16 Silicon Pressurepad for 800MHz only 7566502A01
17 Sirf Module Kit (improved sensitivity): – requires MR5.6 and above PMLD4360_
17a Coax Cable 3366540B01
17b GPS Cover 1566548A01
17c Screw, 5x (M3x8) 0310907A19
17 GPS Module Kit (all software): 0166502N65
17a Coax Cable 3366540B01
17b GPS Cover 1566548A01
17c Screw, 5x (M3x8) 0310907A19
17d GPS Board with Flex 0166502N20
18 Screw for GPS board, 1x (M3x8) 0310907A19
19 Bushing for IP 54 Protection w/o GPS (not shown) 4366504A02
20 UCM Board Kit: GMLN4218_
20a UCM Board Module CLN8041_
20b UCM Board Cover 0786183B01
20c UCM Board Flex 8485615Z02
20d Screw 3x (M5x8) 0310943R55
20 UCM Board Kit: GMLN4562_
20a UCM Board Module AES128 CLN8382_
20b UCM Board Cover 0786183B01
20c UCM Board Flex 8485615Z02
20d Screw 3x (M5x8) 0310943R55
20 UCM-M Board Kit: GMLN5037_
20a UCM-M Board Module AES256 CLN8526_
20b UCM Board Cover 0786183B01
20c UCM Board Flex 8485615Z02
20d Screw 3x (M5x8) 0310943R55
To Next Page
