Motorola SRX 2200 MODEL 3.5

20
21
22
23
24
25
16
15
17
18
19
8
1 Antenna
2 LED
3 Top (Orange) Button
2
4 Microphone
5 Accessory Connector
6 Home Button
7 4–Way Navigation Button
8 Battery Latch
9 Keypad
10 Data Feature Button
11 Menu Select Buttons
12 Main Display
13 3–Position A/B/C Switch
2
14 2–Position Concentric Switch
2
15 On/Off/Volume Control Knob
16 Top Side (Select) Button
2
17 Push-to-Talk (PTT) Button
18 Side Button 1
2
19 Side Button 2
2
20 Battery
2
These radio controls/buttons are programmable.
