Operation Section
12
(3) Power consumption curve
< NOTE >
Condenser inlet air temperatures are at 50% relative humidity.
Evaporator
Inlet Air Dry Bulb Temp.°F (°C) Power Consumption (kW)
Evaporator Inlet Air Wet Bulb Temp.°F (°C)
95(35)
86(30)
77(25)
68(20)
59(15)
59
(15)
68
(20)
77
(25)
86
(30)
50
(10)
95
(35)
0.5
0
1.5
1.0
2.5
2.0
3.5
3.0
4.0
Condenser Inlet Air
Temperature
95°F (35°C)
Condenser Inlet Air
Temperature
50°F (10°C)
Condenser Inlet Air
Temperature
115°F (46°C)
ILL00677-00
