Movincool CM 25 - Lcd Display

Operation Section
29
< NOTE >
The room temperature display range is from 16°F (-9°C) to 140°F (60°C). When the display value
is greater than 99°F, it displays values of 00F (for 100°F), 01F (for 101°F), and 09F (for 109°F).
11 COOL or FAN ONLY Illuminates to indicate COOL on or FAN ONLY on.
12 RUN or AUTO Illuminates to indicate fan mode set to RUN or AUTO.
13 HI or LO Illuminates to indicate fan speed set to High or Low.
14 Room temperature Illuminates temperature in either Fahrenheit (°F) or Celsius (°C) (See Note).
15 Set temperature Illuminates temperature in either Fahrenheit (°F) or Celsius (°C) in COOL mode
(See Note).
16 Day of the week and time Illuminates to indicate day of the week and time.
17 Clock symbol Illuminates to indicate program is running.
18 Key symbol Illuminates to indicate keypad locked.
19 CHECK Illuminates with self-diagnostic codes.
I003164
LCD Display
11
12
13
15
16
19
14
17
18
