Movincool CM 25 - Characteristics

Operation Section
10
2.3 Characteristics
• Value range for each outdoor temperature shown in the graphs is based on the compressor speed.
(1) How to read the characteristics
< NOTE >
Condenser inlet air temperatures are at 50% relative humidity.
IILL00675-00
Evaporator
Inlet Air Dry Bulb Temp. °F (°C)
Cooling Capacity (x10
3
Btu/h)
Evaporator Inlet Air Wet Bulb Temp. °F (°C)
10
5
15
20
25
30
35
40
95 (35)
86 (30)
77 (25)
68 (20)
59 (15)
50
(10)
59
(15)
68
(20)
77
(25)
41
(5)
< Example >
Condition:
Evaporator Inlet Air Dry Bulb : 77 °F (25 °C)
Evaporator Inlet Air Wet Bulb : 59 °F (15 °C)
Condenser Inlet Air Temperature : 95 °F (35 °C)
Cooling Capacity:
Max: 24000 Btu/h
Min: 8000 Btu/h
Condenser Inlet Air
Temperature
115°F (46°C)
Condenser Inlet Air
Temperature
95°F (35°C)
Condenser Inlet Air
Temperature
50°F (10°C)
