Operation Section
9
• Specifications are subject to change without notice.
*1 : With two 20-foot (6.1 m) ducts containing one 90° bend each, supply grill and return grill with filter {0.30 IWG (75 Pa)
external static pressure} on high fan speed.
*2 : Confirm pressure drop of duct, grills, and filter with manufactures specifications.
Signal Connection
Fire Alarm Input
• Dry contact type (recommended)
• No-voltage contact input/Contact
resistance less than 100 ohm
Warning Signal Output 2 A at 30 V DC/AC max. with resistive load
Dimension
W x D x H (without flange) 53 x 32 x 20 in (1346 x 813 x 508 mm)
W x D x H (with flange) 57 x 36 x 20 in (1448 x 914 x 508 mm)
Weight Net/Shipping 310/353 lb (140/160 kg)
Internal Drain Pump Capacity
Pump Rate 5.0 gal/h (19 L/h)
Head 4 ft (1.2 m)
Operating Condition Range
Evaporator
Max. Inlet Air 95°F (35°C), 50% RH
Min. Inlet Air 60°F (15.5°C), 50% RH
Condenser
Max. Inlet Air 113°F (45°C)
Min. Inlet Air 50°F (10°C)
Maximum Duct Length
Cold Duct
*2
120 ft (36.6 m)
Hot Duct
*2
90 ft (27.4 m)
Maximum Sound Level
Measured at 1 m under the
ceiling with evaporator duct and
ceiling tile.
55/55 dB (A)
