Movincool CM 25 - Fan Motor

Operation Section
41
5.19 Fan Motor
(1) Evaporator fan motor
• The CM 25 uses an inverter-controlled DC
evaporator fan motor.
• The evaporator fan motor is operated by DC
motor actuation voltage outputted by the relay
board. Evaporator fan motor speed is
controlled by a relay board built into the fan
motor.
Specifications:
- Rated Voltage: DC 325 V
- Rated Output: High - 192 W, Low - 136 W
- Rotational Speed: High - 880 rpm, Low - 780 rpm
(2) Condenser fan motor
• The CM 25 uses an inverter-controlled DC
condenser fan motor.
• The condenser fan motor is operated by DC
motor actuation voltage outputted from the
relay board. Condenser fan motor speed is
controlled by a relay board built into the fan
motor.
Specifications:
- Rated Voltage: DC 325 V
- Rated Output: High - 322 W, Low - 187 W
- Rotational Speed: High - 865 rpm, Low - 710 rpm
I003146
I003147
