Operation Section
19
ILL00680-00
MF2
(Evaporator
Fan Motor)
Condenser
MF1
(Condenser
Fan Motor)
EXV
(Electronic Expansion Valve)
Compressor
HPRS
(High-Pressure Switch)
CTS2
(Evaporator Pipe
Inlet Thermistor)
RTS1 (WMC Room Thermistor)
Wall Mounted Controller (WMC)
ODS
(Condenser Inlet Air Thermistor)
Evaporator
Accumulator
OLC (Compressor Overload Relay)
CTS3 (Evaporator Pipe Outlet Thermistor)
RTS2
(Evaporator Inlet
Air Thermistor)
CTS1 (Condenser Thermistor)
Flow of Refrigerant
