EDS-508A/505A Series User’s Manual Modbus/TCP Map
B-2
0x0055 3 word Ethernet MAC Address
Ex: MAC = 00-01-02-03-04-05
Word 0 Hi byte = 0x00
Word 0 Lo byte = 0x01
Word 1 Hi byte = 0x02
Word 1 Lo byte = 0x03
Word 2 Hi byte = 0x04
Word 2 Lo byte = 0x05
0x0058 1 word Power 1
0x0000:Off
0x0001:On
0x0059 1 word Power 2
0x0000:Off
0x0001:On
0x005A 1 word Fault LED Status
0x0000:No
0x0001:Yes
0x0080 1 word DI1
0x0000:Off
0x0001:On
0x0081 1 word DI2
0x0000:Off
0x0001:On
0x0082 1 word DO1
0x0000:Off
0x0001:On
0x0083 1 word DO2
0x0000:Off
0x0001:On
Port Information
0x1000~0x1011 1 word Port 1~5 Status
0x0000:Link down
0x0001:Link up
0x0002:Disable
0xFFFF:No port
0x1100~0x1111 1 word Port 1~5 Speed
0x0000:10M-Half
0x0001:10M-Full
0x0002:100M-Half
0x0003:100M-Full
0x0004:1G-Half
0x0005:1G- Full
0xFFFF:No port
0x1200~0x1211 1 word Port 1~5 Flow Ctrl
0x0000:Off
0x0001:On
0xFFFF:No port
0x1300~0x1311 1 word Port 1~5 MDI/MDIX
0x0000:MDI
0x0001:MDIX
0xFFFF:No port
