EDS-508A/505A Series User’s Manual Modbus/TCP Map
B-8
0x005A 1 word Fault LED Status
0x0000:No
0x0001:Yes
0x0080 1 word DI1
0x0000:Off
0x0001:On
0x0081 1 word DI2
0x0000:Off
0x0001:On
0x0082 1 word DO1
0x0000:Off
0x0001:On
0x0083 1 word DO2
0x0000:Off
0x0001:On
Port Information
0x1000~0x1011 1 word Port 1~8 Status
0x0000:Link down
0x0001:Link up
0x0002:Disable
0xFFFF:No port
0x1100~0x1111 1 word Port 1~8 Speed
0x0000:10M-Half
0x0001:10M-Full
0x0002:100M-Half
0x0003:100M-Full
0x0004:1G-Half
0x0005:1G- Full
0xFFFF:No port
0x1200~0x1211 1 word Port 1~8 Flow Ctrl
0x0000:Off
0x0001:On
0xFFFF:No port
0x1300~0x1311 1 word Port 1~8 MDI/MDIX
0x0000:MDI
0x0001:MDIX
0xFFFF:No port
0x1400~0x1413(Port 1)
0x1414~0x1427(Port 2)
20 word Port 1~8 Description
Port Description = "100TX,RJ45."
Word 0 Hi byte = ‘1’
Word 0 Lo byte = ‘0’
Word 1 Hi byte = ‘0’
Word 1 Lo byte = ‘T’
…
Word 4 Hi byte = ‘4’
Word 4 Lo byte = ‘5’
Word 5 Hi byte = ‘.’
Word 5 Lo byte = ‘\0’
Packets Information
0x2000~0x2023 2 word Port 1~8 Tx Packets
Ex: port 1 Tx Packets = 0x44332211
Word 0 = 4433
Word 1 = 2211
