EDS-508A/505A Series User’s Manual Featured Functions
3-58
VLAN Mode
Setting Description Factory Default
802.1Q VLAN Set VLAN mode to 802.1Q VLAN
Port-based VLAN Set VLAN mode to Port-based VLAN
802.1Q VLAN
Management VLAN ID
Setting Description Factory Default
VLAN ID ranges
from 1 to 4094
Set the management VLAN of this EDS. 1
Enable GVRP
Setting Description Factory Default
Enable/Disable
Select the option to enable/disable the GVRP
function.
Enable
Port Type
Setting Description Factory Default
Access This port type is used to connect single devices
without tags.
Trunk Select “Trunk” port type to connect another
802.1Q VLAN aware switch or another LAN that
combines tagged and/or untagged devices and/or
other switches/hubs.
Access
ATTENTION
For communication redundancy in the VLAN environment, set “Redundant Port,” “Coupling
Port,” and “Coupling Control Port” as “Trunk Port,” since these ports act as the “backbone” to
transmit all packets of different VLANs to different EDS units.
Port PVID
Setting Description Factory Default
VID range from 1
to 4094
Set the port default VLAN ID for untagged devices that
connect to the port.
1
Fixed VLAN List (Tagged)
Setting Description Factory Default
VID range from 1
to 4094
This field will be active only when selecting the “Trunk”
port type. Set the other VLAN ID for tagged devices that
connect to the “Trunk” port. Use commas to separate
different VIDs.
None
Forbidden VLAN List
Setting Description Factory Default
VID range from 1
to 4094
This field will be active only when selecting the “Trunk”
port type. Set the VLAN IDs that will not be supported
by this trunk port. Use commas to separate different
VIDs.
None
