EDS-508A/505A Series User’s Manual Featured Functions
3-61
Network without multicast filtering
12345678
Serial ports
Console LAN
9 10111213141516
IGMP Group2
Group 1 Multicast Stream Group 2 Multicast Stream
IGMP Group1 IGMP Group2 IGMP Group1
All hosts receive the multicast traffic, even if they don’t need it.
Network with multicast filtering
IGMP Group2
Group 1 Multicast Stream Group 2 Multicast Stream
IGMP Group1 IGMP Group2 IGMP Group1
Hosts only receive dedicated traffic from other hosts belonging to the same group.
