ioLogik E1200 Series Using the Web Console
Heartbeat
The Heartbeat function can monitor packets being transmitted between a peer-to-peer client and peer-to-peer
server. When the peer-to-peer server does not receive a packet from the peer-to-peer client within a
predefined time interval, the peer-to-peer server will enter safe mode. The default value of heart beat interval
s 60 seconds; this value can be set to between 0 and 65535 (0 means the heartbeat function is disabled).
Sample Peer-to-Peer Configuration
The following is an example of configuring DO (Server IP: 192.168.127.253) to DI (Client IP: 192.168.127.252)
peer-to-peer functionality with two ioLogik E1200 devices.
Server Settings:
Client Settings:
For client settings, the Interval Time setting and On Change percentage setting can be configured.
The following table shows the relationship between the number of rules and the maximum frequency with
which On Change percentage data can be transmitted.
Number of Rules DI max. On Change frequency
1 20 Hz
2 to 20 4 Hz
21 to 40 2 Hz
41 to 50 1 Hz
