PT-7728 User’s Manual Specifications
C-12
0x3000 1 word
Redundancy Protocol
0x0000:None
0x0001:RSTP
0x0002:Turbo Ring
0x0003:Turbo Ring V2
0x3100 1 word
RSTP Root
0x0000:Not Root
0x0001:Root
0xFFFF:RSTP Not Enable
0x3200~0x3211 1 word
RSTP Port 1~18 Status
0x0000:Port Disabled
0x0001:Not RSTP Port
0x0002:Link Down
0x0003:Blocked
0x0004:Learning
0x0005:Forwarding
0xFFFF:RSTP Not Enable
0x3300 1 word
TR Master/Slave
0x0000:Slave
0x0001:Master
0xFFFF:Turbo Ring Not Enable
0x3301 1 word
TR 1st Port status
0x0000:Port Disabled
0x0001:Not Redundant
0x0002:Link Down
0x0003:Blocked
0x0004:Learning
0x0005:Forwarding
0x3302 1 word
TR 2nd Port status
0x0000:Port Disabled
0x0001:Not Redundant
0x0002:Link Down
0x0003:Blocked
0x0004:Learning
0x0005:Forwarding
0x3303 1 word
TR Coupling
0x0000:Off
0x0001:On
0xFFFF:Turbo Ring Not Enable
0x3304 1 word
TR Coupling Port status
0x0000:Port Disabled
0x0001:Not Coupling Port
0x0002:Link Down
0x0003:Blocked
0x0005:Forwarding
0xFFFF:Turbo Ring Not Enable
