Moxa Technologies PT-7728 User Manual

PT-7728 User’s Manual Specifications
C-14
0x3602 1 word
TR2 Ring 1 1st Port status
0x0000:Port Disabled
0x0001:Not Redundant
0x0002:Link Down
0x0003:Blocked
0x0004:Learning
0x0005:Forwarding
0xFFFF:Turbo Ring V2 Ring 1 Not Enable
0x3603 1 word
TR2 Ring 1 2nd Port status
0x0000:Port Disabled
0x0001:Not Redundant
0x0002:Link Down
0x0003:Blocked
0x0004:Learning
0x0005:Forwarding
0xFFFF:Turbo Ring V2 Ring 1 Not Enable
0x3680 1 word
TR2 Ring 2 status
0x0000:Healthy
0x0001:Break
0xFFFF:Turbo Ring V2 Ring 2 Not Enable
0x3681 1 word
TR2 Ring 2 Master/Slave
0x0000:Slave
0x0001:Master
0xFFFF:Turbo Ring V2 Ring 2 Not Enable
0x3682 1 word
TR2 Ring 2 1st Port status
0x0000:Port Disabled
0x0001:Not Redundant
0x0002:Link Down
0x0003:Blocked
0x0004:Learning
0x0005:Forwarding
0xFFFF:Turbo Ring V2 Ring 2 Not Enable
0x3683 1 word
TR2 Ring 2 2nd Port status
0x0000:Port Disabled
0x0001:Not Redundant
0x0002:Link Down
0x0003:Blocked
0x0004:Learning
0x0005:Forwarding
0xFFFF:Turbo Ring V2 Ring 2 Not Enable
Memory mapping from address 0x0000 ~ 0x3FFF.
