6 Installation and commissioning
695831400/02 EN
This section also applies for all winding temperature indicators without plug
connection (without RM option), regardless of whether they are with or with-
out interface.
Limited space in the device can make the connection more dif-
ficult. Connect the data lines before the micro-switches. Route
the cables for the micro-switches through the left-hand cable
gland.
Prepare the following before connecting the micro-switch cable:
1. Strip the cable to a suitable length.
2. Strip a length of 10–12mm of insulation from the wires.
3. Use ferrules if necessary (max. 2.5mm²)
You will need an actuating tool if wires have to be released
from the Push-in terminals used.
An actuating tool is not absolutely necessary for connecting
the wires. When using wires with sufficient buckling resis-
tance, direct plugging is possible without an actuating tool.
Connect the wires to the terminal strip in accordance with the connection di-
agram. To do so:
1. Insert the actuator tool (width 2.5mm) into the opening behind the respec-
tive connection.
2. Route the cable through the front opening until the stop.
