6 Installation and commissioning
70 5831400/02 EN
3. Remove the actuator tool.
Figure52: Micro-switch board connection
1 Connection diagram 2 Terminal strip
6.4.7.3 Connection for micro-switches via M plug (Compact RM)
Devices with a plug connection may be set up with either only
extra-low-voltage circuits or only low-voltage circuits using the
device plug.
