Control Unit Models 9010 LCD and 9020 LCD
20
Configuration
MSA
GB
MSA OPTO-ISOLATOR BOARDS 173 and 174 [board installed by request]
CONFIGURATION 9010/20 LCD FOR SENSORS/TRANSMITTERS FOR GENERAL
PURPOSE BOARD
CV 1 pos. 1-2 External power supplies Drop of solder
[component side]
For applications with
separate external
power supplies
CV 1 pos. 2-3 Internal power supplies Drop of solder
[component side]
Default configuration
Connection type
CURRENT LOOP
TWO-WIRE
CURRENT
LOOP
THREE-WIRE
SENSOR
THREE-WIRE
SENSOR
THREE-WIRE
Type of transmitter Series 27 Df 9500
UltimaXE [2-wire]
Ultima
XE/XIR/XI
RG-3LCD
Catalytic
Thermocondu.
Sensor/trasm.
power supply
VOLTAGE VOLTAGE CURRENT VOLTAGE
Input signal mA mA mV mV
Points to short circuit
CH A CH B
CV1 CV1 pos. 2-3 pos. 2-3 pos. 1-2 pos. 2-3
CV2 CV2 
CV3 CV3 
CV4 CV4 
CV5 CV5 
CV6 CV6 
CV7 CV7 
CV8 CV8
CV9 CV9 pos. 1-2 pos. 1-2 pos. 1-2 pos. 1-2
CV10 CV10
CV11 CV11
CV12 CV12
