Control Unit Models 9010 LCD and 9020 LCD
54
Appendix
MSA
GB
Typical data of the flame detectors UV-IR and IR3
UV-IR IR3 NOTES
Power supply 18-32 VDC 18-32 VDC
24 VDC current consumption 250 mA 250 mA
Output signal 4-20 mA source 4-20 mA source* *sink also
available
St. operating temperature -40°C at +70°C -40°C at +70°C
Weight of aluminium cont. Approx. 3.7 kg 3.5 kg
Dimensions 132x132x120 132x132x120
Material Aluminium/
stainless steel
Aluminium/
stainless steel
Connection cable data
Cable type Shielded at least 80 % Shielded at least 80 %
Max line length with 9010
Max line length with 9020
500 m
500 m
500 m
500 m
Max load at 4-20 mA 600 Ohms 600 Ohms 24 VDC
The data refer to the nominal voltages and with a wire having a 1.5 mm² section
Distances must be derated by 25-30 % approx. if nominal voltages drop by 15-20 %
For other data or more details, consult the specific manual or contact the Technical Support
Department
