Control Unit Models 9010 LCD and 9020 LCD
40
Ordering Information
MSA
GB
11 Ordering Information
Description SAP-P/N
Control unit 9010 LCD general purpose 10093583
Control unit 9010 LCD 4/20 mA 10093585
Control unit 9020 LCD general purpose 10093582
Control unit 9020 LCD 4/20 mA 10093584
Control unit 9010 LCD wall mount 10093662
Control unit 9020LCD wall mount 10093663
Control unit 9020-4 10093664
Front panel 9010 LCD for rack version board 10029768
Front panel 9020 LCD for rack version board 10029769
Front panel 9010 LCD PCB with header 10061926
Front panel 9020 LCD PCB with header 10061927
Fuse F1 - 250 mA [for 230 VAC supply]
Fuse F1 - 500 mA [for 115 VAC supply]
Fuse F3 - 2 A [for 24 VDC supply] 10029845
Fuse F2 - 1 Amp [secondary transformer] 10029844
Standard back terminal board 10029373
Rear terminal board for flat cable 10029843
Rear terminal wall mount version 10061934
Failure relay 10029842
Alarm, Warning, Horn relays 10029841
Jumpers p.5.08 10029840
Optional components
Opto-isolated card common emitter 10094047
Opto-isolated card common collector 10094046
