Setting Parameters
Control Unit Models 9010 LCD and 9020 LCD
33
GB
6.9 Access code 123 - Acceptance of protecting access codes [n° 2; 4; 7; 52; 53]
- Hold down the ENTER button until the green LED flashes.
- Set Access Code 123 using the UP button.
- Confirm by pressing ENTER: The display shows - - -
- Press the ENTER button: The display shows 0
- With the UP button, set the desired access code.
- Confirm by pressing ENTER
P1 TIME-OUT OFF function: enabled
Days of interval between one calibration
and the subsequent calibration: 0 [Alert
function not used]
Peripherals address: 1
Zone: 1
Memorisation of the events: disabled
Password: None
Intervention values of the
alarm thresholds:
C=15, W=15, A=30
Rest mode: C=1°, W=1°,
A=1M
EEEE function: enabled
Operation of the CAUTION
opto-isolator: CAUTION
Operation of the FAILURE
relay: FAILURE
State of the FAILURE re-
lay: And:
Operation of the HORN re-
lay: Acoustic adviser for ex-
ceeding the alarm set-
points and EEEE
State of the HORN relay:
dE
TIME-OUT OFF function:
enabled
Days of interval between
one calibration and the
subsequent calibration: 0
[Alert function not used]
Peripherals address: 1
Zone:1
Memorisation of the
events: disabled
Password: None
Selective for
each channel
The display
shows “def”
P2 Recovery of configuration as per Cus-
tomer Calibration Data Sheet. The origi-
nal configuration required by the
customer as recorded on the Calibration
Data Sheet is set on the board
Recovery of configuration
as per Customer Calibra-
tion Data Sheet. The origi-
nal configuration required
by the customer as record-
ed on the Calibration Data
Sheet is set on the board
Step General purpose board Board 4/20 mA NOTES
